VLT Side Slip Testers


VLT supplies a wide range of Side Slip Testers for cars and light goods vehicles, as well as for heavy goods vehicles. Robust construction for a long life span, especially designed for their special purpose and specifications.


Brochure Downloads

VLT Side Slip Testers

Sku: VLT-015

VLT supplies a wide range of Side Slip Testers for cars and light goods vehicles, as well as for heavy goods vehicles. Robust construction for a long life span, especially designed for their special purpose and specifications.

The VLT Side Slip Testers are connected to a VLT Roller Brake Tester controller and displayed on the digital display or on a TFT-LCD monitor, depending on the configuration of the system.

Technical Specifications

VLT SIDE SLIP TESTERS
VLT 3930 series
Model VLT 3932/M VLT 3933/M VLT 3934/M
Linear up to wheel load of (axle) 3500 kg (7000 kg) 3500 kg (7000 kg) 3500 kg (7000 kg)
Maximum drive-over weight (axle) 5000 kg (10000 kg) 5000 kg (10000 kg) 5000 kg (10000 kg)
Dimensions of drive-over plate 650 x 700 mm 650 x 700 mm 650 x 700 mm
Dimensions of compensation plate 195 x 700 mm 195 x 700 mm 195 x 700 mm
Measuring range toe in / toe out -20 / 0 / +20 mm/m
Contact sensor drive-in / drive out no yes, one
IN
yes, two
one IN, one OUT
Rigid counter plate opposite VLT 39331 VLT 39331 VLT 39331
Optional subframe VLT 3918 VLT 3919 VLT 3919
VLT SIDE SLIP TESTERS
VLT 3940 series
Model VLT 3942/M VLT 3943/M
Linear up to wheel load of 6500 kg 6500 kg
Maximum drive-over weight (wheel) 10000 kg 10000 kg
Dimensions of drive-over plate 950 x 800 mm 950 x 800 mm
Dimensions of compensation plate 245 x 800 mm 245 x 800 mm
Measuring range toe in / toe out -20 / 0 / +20 mm/m
Contact sensor drive-in / drive out no yes, two
IN and OUT
Rigid counter plate opposite VLT 39411 VLT 39411
Optional subframe VLT 3909/T2 VLT3909/T2
