VLT Emission Testers

Sku: VLT-006

Portable VLT Multi Gas Emission Tester for Stand-alone use or as integrated part of Vehicle Test Lane. Extendable with Diesel Smoke Cell.

Robust State of Art Multi gas exhaust analyzer for intensive use. Meet the highest standards and demands of today and tomorrow. This fully digital infrared gas bench technology provides rapid analyses of a vehicle performance and pollutions. Designed as user friendly analyzer for mandatory vehicle testing and fault diagnosis of Petrol – LPG and CNC vehicle emissions.

Standard features:
– Complies with the latest standards.
– OIML Class O accuracy – CE approved.
– Quick and easy operation.
– Test Petrol – LPG and CNG Engines.
– Clear 6 digit LED displays.
– Integrated thermal printer.
– RPM and Oil temperature measurement.
– Step by step test routines.
– Ready to connect up Diesel Smoke Cell.

Technical Specifications

VLT 4588 MK2 EMISSION TESTER
Model VLT4588 MK2
Stand-alone yes, testlane module optional
Power input 230 V -10 % +15 %
Max. power 70 W
RPM 100 – 7500 1/min Optional diesel smoke cell:
CO (carbon monoxide) 0 – 10 % vol Model VLT 4595 MK2
CO2 (carbon dioxide) 0 – 20 % vol Opacity 0 – 99 % / 0 – 9.99 M-1
HC (hydrocarbon) 0 – 10,000 ppm Exhaust probe 4.5 mtr, ø16 mm
O2 (oxygen) 0 – 4 % vol Heat-up power 330 W max.
O2 (oxygen) 0- 25 % vol Measuring cell temperature 100 °C
NOx (optional) 0 – 5000 ppm
Lambda value 0.5 – 4.0
Weight 10 kg
