VLT Above And / Or Under Carriage Special Keyboards


VLT introduced its famous time saving Above and/or Under Carriage Keyboards. A very robust, designed VLT product (suitable for a rough environment), which guides the inspector through the test and in combination with the VLT Test Lane concept database, it tells the inspector by way of green LED’s which items need to be inspected. If there are no fail items, the inspector simply


Brochure Downloads

VLT Inspection Keyboards

Sku: VLT-001

In 1995 VLT introduced its famous time saving Above and/or Under Carriage Keyboards. A very robust, designed VLT product (suitable for a rough environment, which guides the inspector through the test and in combination with the VLT Test Lane concept database, it tells the inspector by way of green LED’s which items need to be inspected.

If there are no fail items, the inspector simply presses the large enter key to confirm that the test is completed.
If there are (major) items that fail, he presses the failed items key once and a red LED lights up, while the green LED goes off.

If the selected item is a minor fail, he presses the failed key twice. The first time the red LED lights up and after the second time both the green and red LED’s are on. This means that this item or items need no repair before passing the overall test. The VLT Above and/or Under Carriage Keyboard has 86 keys and a large enter key. The user can make changes on the keyboard if one is using the VLT Test Lane software module.

If the VLT Above and/or Under Carriage keyboard is installed in the VLT Test Lane concept with 32″ TFT-LCD monitors, all the information on fail (minor or major) is displayed: minor items by green V / red X and major items only by red X. Correction can easily be made by pressing one time more on the same key (repeat function)

Technical Specifications

ABOVE AND / OR UNDER CARRIAGE SPECIAL KEYBOARDS
Model VLT 101034
Overall dimensions 565 x 275 x 60 mm
Number of keys 86 plus ENTER key
Number of LED’s 86 green plus 86 red
Interface out RS 232 / RS 422
Number of keyboards to connect serial: two keyboards by RS 232 available
Number of keyboards to connect parallel: as RS 232 / RS 422 ports available
Power requirement use VLT 101046 power supply
Defenition of keys by VLT if information is known or by customer
Option
Monitor TFT-LCD 15″ can be connected to Above and / or Under Carriage Keyboard if connected to VL Test Lane software module.
